AM20306 U-shaped medical cathethers hot punching processing equipments
Power supply: AC 220V, 10A, 50HZ
Ambient temperature: -20℃ ＋50℃
Working pressure: 0.5-0.8Mpa
Equipment power: 2.1Kw
Power of hot air blower: 2KW
Length of U-shaped hole: ≤6mm
The inner diameter range of the processing tube: inner diameter φ3mm-φ16mm
Applicable materials: PVC, PU, TPU, HDPE, LDPE, PP, PEBAX, etc
Weight: 42KG
Machine size: 460mm*600mm*495mm (length * width * height)
×Enter your message
Product Description
U-shaped catheter hot punching machine AM20306
Equipment introduction
Its working principle is that the medical catheter fastened well by using the fixture which is made of HT62, after it was heated by the industrial-grade hot air blow to a specific temperature, the cylinder begin to output power ,while tools is moved down and guided via the slideway , then punch the U-shaped to the medical catheters.
Equipment characteristics
1- The white steel knives are easy to replace, safe and durable.
2- Industrial hot air blower heating, uniform heating, fast speed.
3- The heating temperature is controllable, and a variety of temperatures are available.
4- The thermostat controls the temperature, and the constant temperature is accurate.
5- Simple operation, button control, with emergency stop button.
6- Compact structure, guided by the sliding block and slide rail, and the punching accuracy is guaranteed.
| Voltage | AC220V/10A/50HZ |
|
Power |
2.1KW |
| Air Pressure | 0.5-0.8MPA |
| Ambient temperature | -20℃ ＋50℃ |
| Power of hot air blower: | 2KW |
| Length of U-shaped hole: | ≤6mm |
| The inner diameter range of the processing tube: |
inner diameter φ3mm-φ16mm |
| Applicable materials | PVC, PU, TPU, HDPE, LDPE, PP, PEBAX, etc |
| Weight | 42KG |
| Machine size | 460mm*600mm*495mm (length * width * height) |
